CommScope HomeConnect Test Probe

CommScope HomeConnect 20dB, Power blocked, 1 GHz Test Probe. Allows RF probing with 20 dB attenuation of KS port to F-connector for servicing.

Features:

• RF probing with 20 dB attenuation

Specifications:

• Insertion Loss         20 dB
• Return Loss, input (Min) 15 dB
• Frequency Response ±1.0 dB
• Impedance 75 ohm
• Operating Frequency Band 5 – 1002 MHz
• Shielding Effectiveness (Min) 100 dB
