Features:

• Features aluminum crossbar and steel clamping jaws with nylon slider pads
• Fits beam flanges from 3" to 14" wide and up to 1-1/4" thick.
• Dual adjusting jaws include concealed locking latches
• Alloy steel D-ring remains centered on crossbar
• For temporary mobile use on horizontal I-beams
• Complies with ANSI Z359.18-2017

Material Specifications

• D-ring: Plated alloy steel; 5,000 lb min. static strength
• Crossbar: Aluminum alloy
• Clamp Jaws: Plated alloy steel

Performance Specifications

• Static Strength: 5,000 lb min.
• ANSI User Capacity: 130 to 310 lb max.
• OSHA User Capacity: 130 to 425 lb max.
