Fluke T5-600 Electrical Tester

The T5-600 Electrical Tester is a versatile troubleshooting tool you can carry to every job site. Use it to check voltage, continuity, and current, all with one compact, rugged tool. Just select volts, ohms, or current and the tester does the rest. For higher voltage applications check out the Fluke T5-1000.  The trendsetting OpenJaw design allows for fast and easy current measurement, safely and without metallic contact with a live conductor. The integrated protection circuit allows it to stay connected to a voltage source longer than a solenoid tester would be able to. Voltage tests are faster and easier than ever before. Just turn the knob to voltage (V) and place your leads on the test points. The T5-600 auto-selects either AC or DC voltage, depending on what is detected. This meter is suitable for both residential or commercial applications and is designed to keep you safe with a CAT III 600 V rating.

Features:

• Measure current up to 100 A without breaking the circuit
• Meter automatically selects AC or DC voltage, up to 600 V
• Resistance measurements up to 1000 Ω plus continuity test
• Work in tight spaces with detachable SlimReach probe tips

Specifications:

• Jaw opening: 12.9 mm (0.5 in)
• Max wire size: 1/0 THHN Cable
• Current range AC rms: 0 to 100.0 A
• Accuracy AC current (50/60 Hz): 3% ± 3 counts
• AC response: Averaging
• Voltage range AC/DC: 0 to 600 V
• Voltage accuracy:
  • AC: 1.5% ± 2 counts
  • DC: 1% ± 1 count
• Resistance range: 0 to 1000 Ω
• Continuity beeper threshold: On at < 25 Ω, off at > 400 Ω
• Volts indicator LED threshold: Guaranteed on by 30 V AC
• Operating temperature: -10°C to 50°C
• Storage temperature: -30°C to 60°C
• Humidity (without condensation):
  • 0% to 95% (5°C to 30°C)
  • 0% to 75% (30°C to 40°C)
  • 0% to 45% (40°C to 50°C)
• Dust/water resistance: Yes
• Operating altitude: 2000 meters max
• Temperature coefficient: 0.1 x (specified accuracy)/°C (< 18°C or > 28°C)
• Measurement Category: IEC 61010-2-032, IEC61010-2-033: CAT III 600 V, 100 A ac
• Agency approvals: CSA, TUV
• Maximum voltage: 600 V between any terminal and earth ground
• Size: 30.5 x 51 x 203 mm
• Weight: 300 g
• Warranty: Two-years
• Battery life: 200-hour zinc chloride, 400-hour alkaline
• Battery type: 2 x AA
• Low battery indicator: Yes
• Current sensor opening: 12.9 mm

What's in the Box:

• (1) 600 V Voltage, continuity, and current tester
• (1) 4 mm detachable probes
• (1) Quick Reference Guide
