Model#: AAT-30

Stock#: SI-AAT30



Sunsight AAT-30 AntennAlign Alignment Tool

SI-AAT30

$6,849.99

THIS ITEM SHIPS FOR FREE!
This item qualifies for Quick Ship. Quick ship items typically ship out the same day you order them as long as the order is placed before 6pm EST, Monday through Friday. Get it by Feb 08

Sunsight AAT-30 AntennAlign Alignment Tool

1-Year easy financing available. Click Here for more information.

Features:

  • Align antenna azimuth, tilt, roll and height better than carriers’ specifications
  • Full-size cellular panel antennas, all Ericsson AIR antennas, small cell housings, and the ability to capture azimuth from the ground
  • Creates an alignment report for individual antennas or the entire site. Includes azimuth, tilt, roll, height and geographic location (Lat/Long)
  • Send reports with all antenna measurements right from the site using any device (Android, iOS, Windows, etc)
  • No additional software, no post-processing, no cables required
  • The lightest instrument on the market at 3.6 pounds; fast, easy to use amount at 2 pounds
  • Most durable unit available; RF shielded, weatherproofed aluminum housing; wet, cold, extreme heat is no match for the AAT-30
Specifications  AAT-30
Azimuth (Heading) Accuracy
(degrees)
+/- .3 RMS
+/- .5 R95
+/- .75 R99
Tilt and Roll Range and
Accuracy (degrees)
+/- 22.5 range
+/- .1 accuracy
AGL Height (ft) +/- 1 standard
+/- .125 premium
Horizontal Accuracy (ft) +/- 1**
Vertical Accuracy - MSL (ft) +/- 2**
Size (in) 17 x 3 x 2.6
Weight (lb) 3.6



** Depends on multipath environment, number of satellites in view, and satellite geometry. Requires SBAS corrections.

The Sunsight AAT-30 AntennAlign Alignment Tool (AAT) ensures accurate antenna positioning during installations, deployments, and operations with its leading-edge techniques. Simple and easy to use, the AntennAlign can be mounted several ways to fit a variety of antenna settings. With its powder-coated aluminum housing, the AntennAlign offers a durable antenna alignment solution that saves time and money.

This alignment tool also offers an on-site quick capture feature that collects position data that is not available prior to climbing. A Sunsight soft carrying case, wrist cuff, and side mount come included with the AAT-30 alignment tool.

Sunsight offers a 3-year manufacturer warranty. For more information please click here to view their policies. If you need to file a claim, click here to start the process.

SI-AAT30
Color: Yellow
Country of Manufacture: United States
Housing Material: Aluminum
Industry: Tower Climbing
Length: 17"
Manufacturer: Sunsight
Warranty?: 3 Year
Weight: 10.20
